FTTH Fiber Optic Splicing Tools Optical Fiber Quick Connect Embedded Cold Splice Cable

Name: FTTH Fiber Optic Splicing Tools Optical Fiber Quick Connect Embedded Cold Splice Cable
Brand: OEM, Powerlink, OEM /ODM
Price: 0.49 USD

Quality FTTH Fiber Optic Splicing Tools Optical Fiber Quick Connect Embedded Cold Splice Cable for sale

Connector Type : SC, SC,FC,LC

Packing : Original Sealed Packing

Type : Fiber Adapter & Connectors

Product insertion loss : ≤0.3dB (max0.5)

Use : ONU

Model Number : SC/UPC SC/APC, SC/UPC SC/APC connector

Port : 1

Application : FTTH FTTB FTTX Network

Place of Origin : Guangdong, China, Guangdong, China (Mainland)

Brand Name : OEM, Powerlink, OEM /ODM

Network : None

Price : $0.49-0.56 / piece

Power Source : Dc 12V

Warranty : 12 Months

MOQ : 10 pieces

Product name : Fiber optic connector

Operating temperature : -40°C~+70°C

Warranty Time : 12month

Contact Now

FTTH Optical Fiber Quick Connector Embedded SC /APC SC/UPC Optical Fiber Cold Splice Cold Splice Covered Cable

Product Description

Product Description:

The Fast Connector (Field Assembly Connector or Field terminated fiber connector, quickly assembly Fiber connector) is a revolutionary field installable optical fiber connector that requires no epoxy and no polishing. The unique design of the patented mechanical splice body incorporates a factory-mounted fiber stub and a pre-polished ceramic ferrule. Using this onsite assembly optical connector, it is possible to improve the flexibility of optical wiring design as well as reducing the time required for fiber termination. The Fast connector series are already a popular solution for optical wiring inside buildings and floors for LAN & CCTV applications and FTTH.

Specification:

ITEM	Technical Parameters
Applicable for	Drop cable / Indoor cable
Applicable for	0.9mm Tight Buffer Fiber, 2.0mm, 3.0mm Drop Cable
Optical fiber diameter	SM(9/125), MM(50/125, 62.5/125)
Optical fiber diameter	125μm ( 657A & 657B )
Tight buffer diameter	250μm
Fiber mode	Single mode
Operation time	About 100s(no fiber cut)
Insert loss	≤ 0.3dB(1310nm & 1550nm)
Return loss	> 50db(PC), > 55db(UPC), > 65db(APC)
Fastening strength of naked fiber	>5 N
Fastening strength of naked fiber holder	>10 N
Tensile strength	>50 N
Using temperature	-40~+85°C
On-line tensile strength (20 N)	IL ≤ 0.3dB RL ≤ 5dB
Mechanical durability (500 times)	IL ≤ 0.3dB RL ≤ 5dB
Drop-off test (drop-off height 4m,once per direction, totally 3 times)	IL ≤ 0.3dB RL ≤ 5dB

Product Image

Packaging & Shipping

PACKAGE:

Standard export carton packing.

DELIVERY TIME:

We promise that all orders will be completed 3-20 days after confirming order.

Detail delivery date should be decided according to production season and order quantity.
